T-type
- polar valve
- T-type
polar valve
T-type
| Valve Body Material | Stainless steel 304 |
|---|---|
| Thermo-actuator | Shape Memory Alloys |
| O-ring | EPDM |
| Pipe size | NPT 3/4 |
| Dimention (inch) | L2.32 x W1.26 x H3.07 |
| Weight (lb) | 0.47 |
| Operating Temperature (℉) | -4 ~ 32 |
| Operating Pressure (psi) | 58 ~ 72 |
| Outflow of Water (mL/min) | 150(at -14℉)/ 200(at -4℉) |
| Installation Condition | Drainage Channel |
